Description
Technical data
- Width: 15m
- Height dimension: 3m/4m
- Center height: 5.4m/6.4 m
- Roof pitch: 18°.
- Portion width: 3m/5m
- Length portion: 5.6m/6.15m
- Minimum length: 9m/15 m
- Maximum length: Unlimited
- Profile structure: 210mm x 110 mm x 4mm
- Pre-roof connection: Internal insertion of the eaves
- Max. wind speed: 100 km/h
- Wind resistance: 0.5 kN / m².
- Floor option: Wood and steel flooring. Aluminum and wood or all-aluminum substructures.
- Covering: Polyester textile 650-900g / m2 covered with PVC, flame retardant to DIN 4102 B1 M2
